    550mm-2300mm Multi Wedge Belt , Power Rated V Belts Eco - Friendly

    Ask Lasest Price
    Brand Name : AiGuoZhe
    Model Number : 10PK1451 10PK1124 10PK1422
    Certification : IATF 16949: 2016 , ISO 9001:2008
    Price : US Dollars $0.5-10.43 pcs
    Payment Terms : T/T
    Supply Ability : 20000 pcs/ day
    Delivery Time : 10-30 days
    • Product Details
    • Company Profile

    550mm-2300mm Multi Wedge Belt , Power Rated V Belts Eco - Friendly

    Product Name: 10PK Series: 10PK1451 10PK1124 10PK1422 Multi Wedge Belt , Ribbed Belt


    Material: CR , NB , EPDM

    Product Details:

    (1) Material: CR /NB

    (2) We can guarantee this quality can be used at least 50,000 Kilometers,

    (3) Easy to install,

    (4) The length can be customized according to your samples,

    (5) It can be customized your own brand and LOGO and the mould is free,


    Notes for Installation of Multi-Wedge Belt:
    With the development of industry, the multi-wedge belt is used in a more demanding environment, and the mistakes in the process of use greatly reduce the user experience. Here is how to avoid the mistakes:

    (1) Use a pipe bar to pry the mounting

    Consequence: the skeleton wire is damaged and the strength of the belt is greatly reduced

    Correct operation: first relax the tensioning wheel, then put in the belt, and then tighten the belt to fit the tension.


    (2) Improper Belt Tension

    Consequences: the belt tension is too low, easy to slip, belt wear, transmission failure; The belt tension is too high, the string and rubber are easy to be separated

    Proper operation: fixed tensioning: fixed tensioning wheel 125N -- 150N/ wedge, automatic tensioning wheel 65-85n/wedge.


    (3) Fault trough installation

    Consequences: when installing the belt, it is easy to be wrongly installed on the rim of the belt wheel, causing wear and tear on the side of the belt and the top

    Correct operation: after the belt is installed, feel the belt around the belt to prevent the belt from being misplaced


    (4) The pulley is not coplanar

    Consequences: the pulley is not coplanar shaft and the pulley plane is not coplanar, two kinds of non-coplanar situation will accelerate the belt wear, or even cause the belt skeleton line out

    Correct operation: gear train is not aligned best < 0.5 °
